DSEG8660 - Mains (Utility) Controller
SAR 0.00
Item number:
DSEG8660
The DSEG8660 is a ATS / Mains (Utility) controller with integral heater designed to work with the DSEG8600 that is configured for use as a multi-set controller. The DSEG8660 allows multiple generators to synchronise with a mains (utility) supply and controls switching power between generator and mains (utility) sources, without loss of supply to the load.
OVERALL SIZE
248.0 mm x 182.6 mm x 45.2 mm / 9.77 ” x 7.19 ” x 1.78 ”
PANEL CUTOUT SIZE
220 mm x 160 mm / 8.66 " x 6.30 "
MAXIMUM PANEL THICKNESS
8.0 mm / 0.31 ”
PRODUCT VARIANTS
G8660-01
